back to main dreadbox page


price : $309.00

2 adsr envelope generators with offset depth control, rate switch (fast-slow)
midi to cv gate and paraphony convertor (with seperate glide controls)
modulation wheel to cv convertor
dip switch for midi channel select / envelope retrigger / unison-paraphony

envelope out: -8v up to 8v, depending on level's position
gate out: 0-5v
cv1 /cv2: 0-5v (5 octaves tracking)
pitch wheel: +/- 1 octave
gate in: accepts up to 12v and activation starts at 1v
22 hp

download the users manual here.
