designed to control all types of mono-synth
super-fast response time
famous kenton build quality
rugged steel case
main cv outputs have high specification 16 bit d/a converters for rock-steady pitches
auxiliary outputs have 12 bit d/a converters
mains powered - internally selectable 230/115 volts (iec socket on back panel)
units are shipped pre-set to the correct voltage for your country
16x2 character lcd display
24 memory locations for setups
midi in socket
midi out socket (for midi channel filter and sysex dumps)
midi thru socket
din sync 24 socket
clock output with selectable 1 to 12 cpqn plus 24 and 48 cpqn modes
any midi channel can be selected for any output
two completely independent main cv outputs
main cv outputs switchable for v/oct & hz/v scaling systems
fine tune & scale are software controllable
transpose (coarse tune) - up & down 12 semitones
adjustable pitchbend range +/- 12 semitones
programmable gate v-trig (up to 15v) or s-trig (with or without pull-up)
multiple and single trigger modes
note priority selection - newest / lowest / highest
old notes are remembered to facilitate trill effects and increase playability
portamento on main cv outputs
auto portamento mode selectable on main cvs (where legato playing turns on portamento)
portamento controllers are selectable
6 programmable auxilary outputs controllable by any midi controller on any midi channel
2 programmable and independant lfos - each with 9 wave shapes including random
lfo can modulate pitch &/or aux outputs
separate controllers for lfo to cv and lfo to auxes
lfos can be synchronised to midi clock
channel filter to 'channelise' an 'omni-on' synth
all parameters are controllable in real-time by sysex
sysex dump and load of current program and any memory
set-up are stored in non-volatile memory for easy recall
midi monitor mode - for easy midi troubleshooting
optional add-on port for kadi or dcb on its own midi channel
