built upon the foundations of its acclaimed predecessor, this new version drastically expands the feature set within the same footprint. all the original goodies are still there, now enriched by a full list of state-based logic functions including a delay
line. faster processing allows perfect handling of audio signals. user editable settings are stored in non-volatile memory. with its versatility and features never seen before, the klavis logica xt will arouse your creativity and bring inventiveness to your
soundscapes.
features:
14 modes of operation:
6 basic logic functions
2 forced states
6 advanced logic functions:
the gater adds-up multiple gate signals while maintaining each triggering with adjustable retrigger gap time
gate to trigger with adjustable pulse length
chronological sequence validation (safe locker)
toss a coin with different chance weighs from the 3 inputs
flip-flop with separate set and reset
digital sample & hold, with adjustable delay/memory line (from milliseconds to several seconds)
3 normalized input jacks + user defined manual button for quad signal handling
settings stored in non-volatile memory
simultaneously normal and inverted outputs (e.g. and & nand)
dedicated divide by two output
continuous manual + bipolar cv control of the mode
led column telling the current operation mode
leds on all outputs indicating the state
led on manual button indicating its default status
settings restored after power cycle
low consumption, skiff-friendly & compact module
specifications:
mechanical:
height: 128.40 mm, 5.06 in, 3 he
width: 25.00 mm, 0.98 in, 5 hp
depth behind panel (with supply cable inserted): 25.00 mm, 0.98 in
